Option Kits

Part

Number

Process Input Signal Conditioner / Isolator Card:

The standard Phoenix AC Drive can follow a 0 to +/- 10 VDC or a 4 to 20 ma Analog Input Signal.  Without an Input Signal Isolator, the Analog Input Signal is directly connected to the signal common of the drive.  The Process Input Signal Conditioner / Isolator Card isolates the Analog Input Signal from the drive signal common and allows the Phoenix AC Drive to accept a wide range of analog input signals (4 to 20 ma or 0 to 192 VDC).  Independent span and zero adjustments allow the user to condition the input signal as required by the application.  Only one of these option cards (3000-4040) can be powered from the drive.

Board Input:  4-20 ma or 0-192 VDC

Adjustments:  Span, Zero

Board Output:  4-20 ma or 0-10 VDC (Isolated from Input)

Required Power Supply:  24 VDC, 75 ma maximum (only one board can be powered from Phoenix AC Drive)

Availability:  Factory installed or Kit Form

3000-4040

Process Input Signal Conditioner / Isolator Card—120VAC:

Provides the same function as the Process Input Signal Conditioner / Isolator Card

(3000-4040), except this board is powered from an external 120VAC source.

Board Input:  4-20 ma or 0-192 VDC

Adjustments:  Span, Zero

Board Output:  4-20 ma or 0-10 VDC (Isolated from Input)

Required Power Supply:  120VAC, 100 ma maximum (typically customer supplied)

Availability:  Factory Installed or Kit Form

3000-4040-120

Non-Isolated 4-20 MA Process Signal Output Card:

The standard Phoenix AC Drive has two 0 to 10 VDC Analog Signal Outputs.  If a 4 to 20 ma Analog Output is required this card should be added.  This card is the same card as the Process Input Signal Conditioner / Isolator Card (3000-4040) shown above.  It is used to convert the drives 0-10V Analog Output to a 4 to 20 ma Analog Output.  Because this card is powered from the drive, the output signal is not isolated from the drive signal common.  Only one of these options cards (3000-4040) can be powered from the drive.  If more than one 4-20 ma output is required or if the input signal must be conditioned or isolated, use the Isolated 4-20 ma Process Signal Output Card (3000-4040-120).

Board Input:  0-10 VDC

Adjustments:  Span, Zero

Board Output:  4-20 ma or 0-10 VDC (Non Isolated)

Required Power Supply:  24 VDC, 75 ma maximum (only one board can be powered from Phoenix AC Drive)

Note: Output Signal can be isolated from drive if customer provides their own 24 VDC isolated supply

Availability:  Factory Installed or Kit Form

3000-4040

Isolated 4-20 MA Process Signal Output Card:

Provides the same function as the Non-Isolated 4-20 ma Process Signal Output Card except the Output Signal is isolated from the drive signal common.  This card is the same card as the Process Input Signal Conditioner / Isolator Card—120 VAC (3000-4040-120) shown above.  It is used to convert the drives 0-10V analog output to a 4 to 20 ma Analog Output and Isolate it.  Because this card is powered from a 120 VAC source, the output signal is isolated from the drive common.

Board Input:  0-10 VDC

Adjustments:  Span, Zero

Board Output:  4-20 ma or 0-10 VDC (Isolated from Drive)

Required Power Supply:  120 VDC, 100 ma maximum (typically customer supplied)

Availability:  Factory Installed or Kit Form

3000-4040-120

0-15 PSI Pneumatic Signal Follower Card:

The 0-15 PSI Pneumatic Signal Follower Card gives the drive the ability to accept a pneumatic pressure source as an input reference signal from the outside world.  A 1/8 inch ID hose fitting is provided for customer connection.  Independent span and zero adjustments allow the user to easily calibrate the input to the drive.

Board Input:  3-15 PSI, pneumatic neoprene 1/8” ID hose to on-board transducer nipple

Adjustments:  Span, Zero

Board Output:  4-20 ma or 0-10 VDC

Board Power Supply:  24 VDC, 50 ma maximum, (one board can be powered from Phoenix AC drive)

Availability:  Factory Installed or Kit Form

3000-4045

115VAC Operator (Digital Input) Interface Card:

The Phoenix AC Drive is designed to accept contact closures and/or logic inputs at a 24 VDC level.  If the drive will be operated using remote Pushbuttons and Selector Switches powered at the 115 VAC level, this card should be used.  This card accepts120 VAC logic level input signals and converts them to 24 VDC logic level inputs.

Required Power Supply:  Customer supplies 12 VAC, 30A minimum

Availability:  Factory Installed or Kit Form

3000-4050

Removable RS-232 Isolated Communications Interface with Cable:

This Removable Communications Interface with Cable option allows the Phoenix DX or EX AC Drive to communicate via RS-232 with a Laptop.  This option is very useful to field program drives using a laptop with Drivemaster.  The interface cable is 10 feel with a standard D9 female connector.

Availability:  Kit Form Only

Special Note:  If a Laptop is only equipped with a USB port, an off-the-shelf USB Serial Adapter is required.

3000-4225-D9

Isolated Communications Card (Metasys N2):

This Communications Option Card allows the Phoenix DX AC Drive to communicate via RS-232/422/485 Serial Communications.  Metasys N2 is a Johnson Controls communication protocol.  Each communication link can handle 32 devices with address range from 1 to 255.  Data rate of 9,600 baud with no parity is the only support.  For easy networking, a removable screw connector is provided.   Operational commends and selected drive parameters are accessible via Metasys N2 protocol.

Availability:  Factory Installed or Kit Form

3000-4135-2

Ethernet Communications Card (Modbus TCP):

With this option card, a single drive or a group of drives can be networked together and given an Internet Address.  Once connected to the Internet, your drives can be monitored, configured, and controlled from anywhere in the world.  Password protection is provided to prevent unauthorized access and control.

Availability:  Kit Form Only

Special Note:  One Ethernet Communications Card May be used with up to 32 Drives.  Requires the addition of one Isolated Communications Card (RS-232/422/485, Modbus RTU), P/N: 3000-4135-1 per drive.

3000-4235

I/O Expansion Board:

Phoenix DX and Phoenix EX AC Drives include 8 Digital Inputs, 2 Digital Outputs, 2 Analog Inputs, and 2 Analog Outputs as standard.  If additional Inputs and Outputs are required, the Phoenix DX/EX I/O Expansion Board may be added.  With the addition of the Phoenix DX/EX I/O Expansion Board, the drive can support up to 8 Digital Inputs, 7 Digital Outputs, 3 Analog Inputs, and 3 Analog Outputs.  The Phoenix DX/EX I/O Expansion Board is fully configurable.  You may add up to 5 Digital Outputs, 1 Digital Input, and 1 Analog Output.

Availability:  Factory Installed or Kit Form

3000-4150

HOA Switch:

A Factory installed Hand-Off-Auto switch allows the operator to select how the drive will be operated.  In “Hand” Mode the drive is operated using local Start and Stop Pushbuttons or the Keypad Pushbuttons and a local Speed Reference signal.  In “Auto” Mode the drive is controlled by remote Start and Stop Pushbuttons or contacts and a remote Speed Reference signal.

Availability:  Factory Installed Only

Included as Standard on Phoenix AC Drives with Bypass

PDX-HOA-SW

Local/Remote Switch:

A Factory Installed Local-Remote switch allows the operator to select where the logic signals that control the drive will come from.  In “Local” Mode, they will come from Local Start/Stop Pushbuttons or from the Pushbuttons on the drive Keypad.  In “Remote” Mode they will come from remote Start and Stop Pushbuttons or contacts.

Availability:  Factory Installed Only

PDX-LR-SW

Auto/Manual Switch:

A Factory Installed Auto-Manual allows the operator to select where the Speed Reference Signal will come from.  In “Auto” Mode, the reference signal will come from the remote source.  In “Manual” Mode the reference will come from the drive Keypad.

Availability:  Factory Installed Only

PDX-AM-SW

Speed Potentiometer:

A Factory installed speed potentiometer gives local speed control by potentiometer.

Availability:  Factory Installed Only

PDX-POT

Automatic-Bypass Adder for Size 0 with Manual Bypass:

This Factory Installed option can be added to a Phoenix AC Drive with Manual Contactor Bypass to automatically transfer to Bypass Mode when a fault is detected.

Availability:  Factory Installed Only

PDX-ABP0

Automatic-Bypass Adder for Size 1 with Manual Bypass:

This Factory installed option can be added to a Phoenix AC Drive with Manual Contactor Bypass to automatically transfer to Bypass Mode when a fault is detected.

Availability:  Factory Installed Only

PDX-ABP1

Automatic-Bypass Adder for Size 2 with Manual Bypass:

This Factory installed option can be added to a Phoenix AC Drive with Manual Contactor Bypass to automatically transfer to Bypass Mode when a fault is detected.

Availability:  Factory Installed Only

PDX-ABP2

Automatic-Bypass Adder for Size 3 with Manual Bypass:

This Factory Installed option can be added to a Phoenix AC Drive with Manual Contactor Bypass to automatically transfer to Bypass Mode when a fault is detected

Availability:  Factory Installed Only

PDX-ABP3

Backlight for Keypad (ROM) Display:

This Factory installed option provides backlighting for the 2-line keypad display (ROM).

Availability:  Factory Installed Only

PDX-BKLT

Ribbon Cable Extender for Keypad (ROM) - 6’:

This cable allows the user to remove the Phoenix Realtime-Operator-Module (ROM) from its normal location on the face of the drive module and remotely mount it up to six feet away.  This cable is typically used when the drive module is mounted inside another enclosure (Nema 12 or Nema 4) and the Keypad must be mounted on the door of the enclosure.

Availability:  Factory Installed or Kit Form

PDX-CBL-6

Bezel Assembly Keypad (ROM):

This meal frame covers the cutout you would normally make in the door of an enclosure to remotely mount the Realtime-Operator-Module (ROM).

Availability:  Factory Installed or Kit Form

PDX-BZL

Remote Keypad (ROM) Kit:

The Remote Keypad Kit converts the standard Phoenix Realtime Operator Module (ROM) to a Remote Keypad Assembly that can be mounted up to 500 feet from the drive.  Two adapter boards, a small power supply, and the Phoenix Keypad Bezel Assembly are included.  The customer must provide the required six conductor shielded cable (Belden 9730 or equivalent) and 115 VAC at the Remote Mounting Location to power the Keypad.

Availability:  Kit Form Only

PDX-RMT

Floor Stand Kit for Size 3 Nema 1 Enclosed Phoenix Drives:

This floor stand kit allows the standard Wall Mounted Size 3 Phoenix AC Drive to be floor mounted.  Floor stand kit adds 14” to enclosure height.

Availability:  Factory Installed or Kit Form

Included as standard on Size 3 Drives with Disconnect and Fuses and Bypass

PDX-FS1

Size 0, 1, & 2 Seal Kit for Nema 12:

US Drives will Factory seal a Nema 1 Enclosed Drive so the drive heatsink assembly can be through hole mounted with the heatsink and DC Bus Choke extending outside a Nema 12 Control Enclosure.  The Nema 1 Enclosed drive must be through hole mounted inside the Nema 12 enclosure.

Availability:  Factory Installed Only

PDX-N12-SEAL

Size 3 Seal Kit for Nema 12:

US Drives will Factory seal a Nema 1 Enclosed Drive so the drive heatsink assembly can be through hole mounted with the heatsink and DC Bus Choke extending outside a Nema 12 Control Enclosure.  The Nema 1 Enclosed drive must be through hole mounted inside the Nema 12 enclosure.

Availability:  Factory Installed Only

PDX-N12-SEAL3

Size 0 Seal Kit & Fans for Nema 4:

US Drives will Factory seal a Nema 1 Enclosed Drive so the drive heatsink assembly can be through hole mounted with the heatsink and DC Bus Choke extending outside a Nema 4 Control Enclosure.  The Nema 1 Enclosed drive must be through hole mounted inside the Nema 4 enclosure.  Nema 4 fans will be provided in the heatsink assembly.
